Whip Base Installation
- Each mooring whip base or mount should be aligned with the tender’s cleat.
- The further apart the attachment points, the better.
- The whips should be perpendicular, 90°, to the tender.
Whip Poles
- Connect the two whip halves, making sure to align the end of the whip with the cleat.
- The two halves can be permanently fixed together using an epoxy adhesive if required, although not doing so will enable
easy stowage.
- Insert the whips into the bases.
- Do not be afraid to bend the poles. However, it is important that when under full tension, the tip is never lower than the
base.
- Over bending the pole will actually reduce the tension / performance of the whip and increase the risk of damage.
Lines
- When securing the tender, bow and stern, two spring lines must be used.
- Adjust the lines so they are taught.
- Prevent the whips from bending sideways.
- Every effort should be made to keep the whips perpendicular to the cleats on the tender.
- The breast lines should be at a length that holds the tender a minimum of 1.8 metres from the dock or gunwale.
Warranty
- Twelve months warranty is offered, provided that the above guide is followed.
- Our tender whips are not designed to be used in conditions above Force 4.
- Therefore, the warranty will not cover any damage incurred during such conditions.
